System Accessibility and Availability
-
Secure in-band and out-of-band remote serial console access
-
Browser access with an intuitive GUI
-
Terminal-based access with a menu-driven UI
-
Modem dial-in/dial-back/dial-out access
-
Front USB ports for storage or USB-based PC cards
-
Laptop USB Console (LUC) port for local console access via laptop
-
Dual Ethernet ports allow fail control or dual IP address access
-
Dual power supply
-
Serial Console Management
-
Auto-sensing DTE/DCE feature supports a direct connection to Cisco network switches (and other compatible devices) without rollover cables for more convenient IT infrastructure deployment
-
Online/Offline detection of connected serial devices (including terminal blocks) – automatically send event notifications when the devices are offline for device status monitoring
-
Convenient and simple serial device access via selectable Telnet/SSH and third-party clients such as PuTTY
-
Easy port access via selectable ActiveX or Java serial viewer
-
Comprehensive viewer functions – copy/paste, logging, data import, macros, broadcasting and message board
-
Sun Solaris ready – Sun “break-safe”
-
Alert Strings – whenever one of the pre-defined strings matches the message sent from the serial devices, you will be informed by serial console server via SNMP Trap alert and/or an email
-
Command filter – administrators can restrict users to execute only pre-defined commands
-
Multiple users can simultaneously access the same port – up to 16 connections per port
-
Modes for simultaneous access – Exclusive/Occupy/Share
-
Integrates with ATEN PDU* products for power management of each port
-
Security
-
Supports secure login from browsers with TLS 1.2 data encryption and RSA 2048-bit certificates
-
Configurable user permissions for port access and control
-
Local and remote authentication and login
-
Third-party authentication via RADIUS, TACACS+, LDAP/AD and Kerberos
-
IP and MAC address filter for enhanced security protection
-
High-Grade Security – supports FIPS 140-2 level 1 security standards that use an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #1747, #2398, #2473)
-
Supports security level configuration – High, Medium-high, Medium or Custom, to ensure a fine granularity of network access control
-
System Management
-
System configuration via web browser, Telnet/SSH client and local console
-
System log and event login
-
Event Destination – Event logs will be saved to Log server, Syslog server, and USB drive
-
SNMP agent
-
Event notification – supports notification of SMTP email, SNMP Trap, and SMS (with additional mobile devices)
-
Backup / Restore system configuration and upgradeable firmware
-
Multi-browser support – Internet Explorer, Chrome, Firefox
-
NTP for time server synchronization
-
IPv4 / IPv6 support
-
Integrates into CC2000 software for centralized data center management
-
Integrates into CCVSR software for user session recording
-
Serial Device Management
-
Versatile serial operating modes – Console Management, Console Management Direct, Real COM Port, TCP Server/Client, UDP Server/Client, and Virtual Modem
-
Real COM driver for Windows 2000 or higher and Windows Server 2003/2008
-
Real TTY driver for Linux
-
Fixed TTY driver for UNIX**
-
Supports baud rates of 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200, 230400 bps
LanguageMulti-language web-based GUI – available in English, German, Japanese, Korean, Russian, Simplified Chinese and Traditional Chinese
Connection |
16 |
Connectors |
Serial |
16 x RJ-45 Female |
LAN Ports |
2 x RJ-45 Female |
Power |
2 x IEC 60320/C14 |
PON |
1 x RJ-45 Female (Reserved) |
Modem |
1 x RJ-45 Female |
USB Port |
3 x USB Type A Female |
Laptop USB Console (LUC) Port |
1 x Mini USB |
Local Console |
1 x RJ-45 Female |
Switches |
Reset |
1 x Recessed Pushbutton |
Power |
2 x Rocker Switch |
Maximum Input Power Rating |
100-240V~, 1A, 50/60Hz |
Power Consumption |
AC110V:15.4W:104BTU
AC220V:14.9W:102BTU |
LEDs |
Serial |
16 (Green) |
10/100/1000 Mbps |
2 (Red / Orange / Green) |
Power |
2 (Blue) |
Mode of Operation |
Console Management,Console Management Direct,Real Com Port, TCP Server/Client, UDP Server/Client, Virtual Modem |
Environmental |
Operating Temperature |
0 - 40˚C |
Storage Temperature |
-20 ~ 60˚C |
Humidity |
0 - 80% RH, Non-condensing |
Physical Properties |
Housing |
Metal |
Weight |
4.48 kg ( 9.87 lb ) |
Dimensions (L x W x H) |
43.72 x 32.98 x 4.40 cm
(17.21 x 12.98 x 1.73 in.) |
Package Contents
-
1x SN0116CO Serial Console Server
-
1x Laptop USB Console Cable
-
2x Power Cords (AC models)
-
1x Mounting Kit
-
2x Lok-U-Plugs
-
1x Lok-U-Plug Installation Tool
-
1x Foot Pad Set (4 pcs.)
-
1x User Instructions
