Hardware
-
Advance processor provides lossless and low latency video transmissions up to 1920 x 1200 @ 60Hz; 24-bit color depth
-
Support standard HDMI resolutions from 640 x 480 up to 1920 x 1200
-
USB Virtual Media Support
-
Compliant with HDMI 1.4a and HDCP 1.4
-
Auto-MDIX – automatically detects cable type
-
Built-in 8KV/15KV ESD protection and 1KV surge protection
-
Slim, light and fanless design for silent operations that are energy efficient
-
Support connection via Gigabit Ethernet port
-
Rack Mountable* and Wall Mountable
-
Mounting options:
-
VE-RMK 1U Extender Rack Mount Kit*
-
Note: *Refer to www.aten.com for more regarding the VE-RMK 1U Extender Rack Mount Kit.
Management
-
Remotely access computers on your KVM installation via intranet
-
OSD (On Screen Display) on the Receiver configures both Tx/Rx units
-
EDID Expert™ – selects optimum EDID settings for smooth power-up and highest quality display
-
Video Compression Level – allows you to increase/decrease the video quality to adjust for appropriate network bandwidth
-
CLI – administrators can control all KE devices via RS-232 or Telnet by issuing commands
-
RS-232 serial ports – allow you to connect to a serial terminal for text menu, CLI, or serial devices such as touch screens and barcode scanners
-
Compatible with all KE devices
Security
-
Dedicated LAN port for KE direct connections – can be isolated from the corporate network
-
Secure data transmission – AES encryption to secure Video/Keyboard/Mouse/Data transmission
-
Supports industry standard Transport Layer Security (TLS) protocol
Virtual Media
-
Virtual Media enables file transfers, OS patching, software installations and diagnostic testing
-
Support USB 2.0 DVD/CD drives, USB mass storage devices, PC hard drives and ISO images
-
Support Smart Card/CAC Reader
Advanced Features**
-
Flexible connections – allows multiple extender and matrix connections for multi-display installations and video wall applications
-
“Push” and “Pull” – share content instantly by just one click
-
Fast Switching – switch between different remote video resolutions on a local display within 0.3 second
-
Boundless Switching - simply move the mouse cursor across screen boundaries to switch between different receivers
-
Video Walls – create multiple video walls with up to 8 x 8 (64 displays max.) in each layout
-
Advanced Scheduling – improves efficiency and saves costs by allowing connections to be set based on time and date
-
Virtual Transmitter – to stream video, audio, USB, and serial sources independently
-
Support both internal and external authentication – external authentication supports LDAP, Active Directory, RADIUS and TACACS+
-
Advanced User Authorization Settings – administrators can set four access modes of permissions on Tx devices for collaboration or to avoid interference among users
-
Configurable user and group permissions for access and control of KE devices
-
Tx grouping of up to 4 sets of KE transmitters to support multi-display applications
Note: **These advanced functions are supported when the KE devices are managed by KE Matrix Management Software (CCKM)
Recommended Network Switches
-
Below are the network switches that have passed ATEN's stress tests using the KE Series extenders. Our tests streamed content over a network with a resolution of 1920 x 1200 @60Hz (KE69 Series) and 3840 x 2160 @30Hz (KE89 Series), 24bit color depth at 60 frames per second.
-
Cisco Catalyst 2960X / Catalyst 2960XR / Catalyst 3750
-
HP Procurve 2920
-
H3C S5120
-
Huawei S5700
-
DLink DGS-1510
Connectors |
Virtual Media |
2 x USB Type A Female (Black) |
Console Ports |
2 x USB Type A Female (Black)
1 x HDMI Female (Black)
1 x DB-9 Male (Black) |
Power |
1 x DC Jack (Black) |
LAN Ports |
1 x RJ-45 (Black) |
Switches |
Reset |
1 x Semi-recessed Pushbutton |
LEDs |
10/100/1000 Mbps |
1 (10: Orange / 100: Orange & Green / 1000: Green) |
Power |
1 (Blue) |
Emulation |
Keyboard / Mouse |
USB |
Power Consumption |
DC5V:4.35W:46BTU |
Video Resolution |
Up to 1920 x 1200 @ 60Hz |
Environmental |
Operating Temperature |
0–50°C |
Storage Temperature |
-20–60°C |
Humidity |
0–95% RH, Non-condensing |
Physical Properties |
Housing |
Metal |
Weight |
0.64 kg ( 1.41 lb ) |
Dimensions (L x W x H) |
18.20 x 11.75 x 2.87 cm
(7.17 x 4.63 x 1.13 in.) |
