SLS-FUJITSU-CG-512PA1V

Fujitsu 1/3" Gece & Gündüz Kamerası, Çıkarılabilir IR Kesme Filtresi (IR Cut Filter) özelliği, DSP, 230VAC, 540TVL, Lens harici olarak temin edilmelidir (Fujitsu 1/3" Day/Night Camera with Switchable IR Cut Filter, DSP, 230VAC, 540TVL, Lens is not included with the camera)

Bu Ürünün Yer Aldığı Kategori(ler)

İlginizi Çekebilir

DN-16024

DN-16046

DN-16047

KAM-DS-2CD2125FWD-IS

NG-VMC3040S

PL-LRP-101C-KIT

PL-LRP-101CE

PL-LRP-101U-KIT

PL-LRP-822CS

PL-NVR-1615

SA-NX-BLK-NOTE7777

SLS-DSP-CP-300

SLS-DSP-CP-350

SLS-ENEO-EHL-W/ECLKA

SLS-ENEO-PGS-2101

SLS-ENEO-VKC-1332/3.6SMD

SLS-ENEO-VKCD-135

SLS-TG5Z2813FCS-IR

SLS-TG5Z8513FCS-IR

- Resolution of 540 Horizontal Lines (Colour)
- Automatic Gain Control (AGC)
- High Sensitivity of 0.1Lux at F1.2 (B&W)
- Removable IR Cut Filter
- Back Light Compensation (BLC)
- Electronic Shutter Control (ESC)
- Automatic AI/DC Control Selection (Depend on Lens)
- Integrated Eclipse and Flickerless Function
- Automatic White Balance with Hold Function (AWB)
- Auto Blemish Compensation (up to 32 Pixels)
- Adjustable Video Transmission Distance
- Supply Voltage: 230VAC
- Video Standard: CCIR/PAL
- System: Day & Night
- Sensor size: 1/3"
- Imager: CCD, Sony Super HAD Interline Transfer CCD
- Active picture elements: Approx. 440,000, 752(H) x 582(V)
- Signal processing: Digital (DSP)
- Synchronization: Internal/AC line lock
- Signal-to-noise ratio: 48dB (AGC OFF)
- Gamma correction: 0.6/1.0
- Horizontal resolution: 540TVL, (colour), 570TVL (b&w)
- Sensitivity (at 50% video signal): 0,8Lux, at colour, 0.1Lux (B&W) at F1.2
- Light control range (ESC + AGC): 30,000:1
- Light control range (AI + AGC): 600,000:1 (Iris range F1.4 ~ F300)
- Electronic shutter control (ESC): 2.000:1 (On/Off switchable)
- Integration rate: No
- Signal amplification: 3 steps (for transmission distance short, middle, long)
- Automatic gain control (AGC): Normal, High and ON/OFF switchable
- Backlight compensation: BLC, eclipser, ON/OFF switchable
- White balance (AWB): Auto/Hold
- Blemish compensation: Automatic blemish detection and compensation (for up to 32 pixels)
- Aperture Correction (APC): Horizontal and vertical
- Flickerless function: 120sec., ON/OFF switchable
- Eclipser function: On/Off, Treshold, Eclipse and Grey level
- IR cut fitler: Yes, Motorized, switchable filter. Automatic function depend on the amount of light. Automatic/manual selectable by OSD menu. In, removed filter position, the colour signal will be switched off. Selectable time delay: 5Sec. or 30Sec., External D&N, switching via external contact input
- OSD function control: OSD camera setup: Pixel correction, Eclipser, Day&Nignt, BLC, AWB, Chroma, ESC, AGC, Flickerless, Aperture, Masking (Window blanking), Transmission distance compensation
- Lens mount: C/CS mount
- Usable iris controls: Manual iris, Auto-Iris/DC controlled
- Auto-Iris voltage supply: 9VDC (40mA max.)
- External adjustments: Flange focus Switch for setup menu
- Video outputs (type): CVBS
- Video outputs: 1Vp-p, composite, 75ohms, BNC
- External connections: Auto-/DC Iris (4-pin), Video (BNC), Day/Night switching (2-pin), Power input
- Serial interfaces: No
- Camera mount: 1/4" - 20 UNC thread on top and bottom
- Supply voltage: 230VAC, (+/-15%) 50Hz
- Power consumption: Approx. 12watts
- Temperature range (Operation): 0 ~ +40°C
- Weight: 400g
- Parts supplied: 4-pin plug, Allan key, Manual on CD ROM
