ATEN-VC060
DVI EDID Emülatörü (DVI EDID Emulator)
Bu Ürünün Yer Aldığı Kategori(ler)

-
Superior video quality – HDTV resolutions of 480i, 480p, 720i, 720p, 1080i, 1080p (1920 x 1080); VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
-
EDID Wizard – allows a user an easy way to manage EDID settings
-
EDID mode selection – Default, Learning , Programming
-
Automatically manages EDID communication between connected devices
-
Signaling rates up to 2.25 Gbits in support of 1080p display
-
LED indication of video source devices
-
Supports wide screen
-
Supports hot-plugging
-
Non-Powered *
* If the video source is not receiving enough power an external power cord should be connected.
Video Input |
Interfaces |
1 x DVI-I Female (White) |
Impedance |
100 Ώ |
Video Output |
Interfaces |
1 x DVI-I Female (White) |
Impedance |
100 Ώ |
EDID Settings |
EDID Mode: Default / Learn / Customized (EDID Wizard support) |
Connectors |
Power |
1 x DC Jack |
Power Consumption |
DC5V:0.13W:1BTU |
Environmental |
Operating Temperature |
0 - 50 ºC |
Storage Temperature |
-20 - 60 ºC |
Humidity |
0 - 80% RH, Non-Condensing |
Physical Properties |
Housing |
Metal |
Weight |
0.15 kg ( 0.33 lb ) |
Dimensions (L x W x H) |
7.90 x 7.86 x 2.45 cm
(3.11 x 3.09 x 0.96 in.) |
