Açıklama

  • Connects any of 32 video sources to any of 32 displays in combination with ATEN Modular Matrix Solutions
  • Built-in Scaler on each output port converts input resolutions into the display’s native resolution
  • Supports 4K resolutions up to UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0)
  • Seamless Switch™ – ATEN FPGA design unifies video formats to provide continuous video streams, real-time switching, and stable signal transmissions*
  • Video Wall – allows you to create custom video wall layouts via intuitive web GUI
  • Live stream of connected video channels and image preview of video wall layouts via web GUI
  • Calendar-based scheduling plays connection profiles synchronized with real-time clock
  • EDID Expert™ – selects optimum EDID settings for smooth power-up and highest quality display
  • Multiple Control Methods – system management via front-panel pushbuttons, RS-232, RS-485/422, and Ethernet (Telnet / Web GUI) connections
  • Hot-pluggable fan and power modules for easy maintenance and higher reliability
  • Flexible system expandability via hot-swappable tool-free installation of I/O boards
  • Optional redundant power supply that ensures reliability for mission-critical applications
  • Audio-enabled, HDMI audio can be extracted, and stereo audio can be embedded (VM7804/VM8804)
  • HDMI (3D, Deep Color) (VM7804/VM8804); HDCP 1.4 compatible
  • Consumer Electronics Control (CEC) support (VM7804/VM8804)
  • ESD protection for HDMI
  • Firmware upgradeable
  • Aluminum frame provides light-weight design
  • Rack mountable (9U design)
    * Note: If Seamless Switch is enabled, the video output will not display 3D, Deep Color, or interlace (i.e., 1080i) resolution features. To use these features, you must disable Seamless Switch.



Board Input 8 x Slot
Board Output 8 x Slot
Video Input
Interfaces Depends on which I/O board is inserted
Max. Data Rate 15.2 Gbps (3.8Gbps per Lane)
Audio
Input Depends on which Input board is inserted
Output Depends on which Output board is inserted
Control
RS-232 Connector: 1 x DB-9 Female (Black)
Serial Control Pin Configurations:
Pin2 = Tx, Pin 3=Rx, Pin 5= Gnd
Baud Rate and Protocol:
Baud Rate:19200, Data Bits:8, Stop Bits:1, Parity: No, Flow Control: No
RS-485/RS-422 Connector: 1 x Captive Screw Connector, 5 Pole
Ethernet Connector: 1 x RJ-45 Female
EDID Settings EDID Mode: Default / Port1 / Remix / Customized (EDID Wizard support)
Power
Connectors 1 x 3-Prong AC Socket
Maximum Input Power Rating 100-240 VAC; 50-60Hz; 1.0A
Consumption 800W
*A redundant power supply is optional.
Environmental
Operating Temperature 0 - 40°C
Storage Temperature -20 - 60°C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Dimensions (L x W x H) 48.20 x 47.19 x 39.90 cm (18.98 x 18.58 x 15.71 in.)
Weight 18.20 kg ( 40.09 lb )
Carton Lot 1 pc



Package Contents

  • 1x VM3200 32 x 32 Modular Matrix Switch
  • 1x Power Cord
  • 1x Terminal Block connector
  • 1x User Instructions
