                    [short_description] => Tumtec Fiber Optic Fusion Splicer (FST-83A)
                    [long_description] =>



	• Core to Core

	• 3S Turn On Time

	• 6S Splicing Time

	• 5” Color LCD Touch Screen

	• 5200mAh Battery Capacity

	• 500X Magnification













				Model


				FST-83A





				Dimension


				140W x 165L x 145H mm (including rubber bumper) 130W x 165L x 135H mm (excluding rubber bumper)





				Weight


				2.0KG (including rubber bumper) 1.7KG (excluding rubber bumper) 0.38KG (battery)





				Number of Fiber


				Single





				Applicable Fibers


				SM(ITU-T G.652&G.657) / MM(ITU-T G.651) / DS(ITU-T G.653) / NZDS(ITU-T G.655)





				Compatible Fiber / Cable


				0.25-3.0 mm / Indoor Cable (0.9mm/2.0mm/2.4mm)





				Cleaved Length


				Diameter: 0.125-1 mm / Cleave Length: 8-16 mm





				Cladding Diameter


				80-150 pm





				Splicing Mode


				Multiple splicing modes





				Typical Splice Loss


				0.04db





				Return Loss


				>> 60 dB





				Lighting


				1 Powerful White LED and illuminated Keypads





				Splicing Time


				6-8 seconds





				Estimated Splice Loss


				Available





				Protection Sleeve Length


				20-60 mm





				Heating Mode


				Multi heating modes





				Heating Time


				typical heating time: 30 sec





				Results Storage


				The last 5000 results





				Tension Test


				1.5-2.0N





				Operating Condition


				Operating Altitude: 0-5000m above sea level, 0.95% relative humidity, - 10-50°C, Max Wind 15m/s





				Storage Condition


				0-95% relative humidity, -40-80°C





				Display


				90° bi-directional view, 5.0" 800*480 Color High Resolution Display with touch screen





				Fiber View & Magnification


				X, Y, XY, X/Y : 500X Magnification





				Power Supply


				AC Input 100-240V, DC Input 12-15V





				No of Splice / Heating with Battery


				5200mAh Battery Capacity, Typical above 280 times (Splice+Heat)





				Operating Methods


				Button / Touch screen





				Automatic Calibration


				Automatic arc calibration by air pressure and temperature





				Electrode Life


				5000 arcs, can be extended by using an electrode grinder





				Terminal


				USB2.0 / Phone Jack
