ATEN-SN0148CO

48-Port Serial Console Server with Dual Power/LAN

EAN: 4719264647710
Bu Ürünün Yer Aldığı Kategori(ler)

İlginizi Çekebilir

AT-2801FX/SC

AT-AR740

AT-FS980M/28

AT-GS950/8POE

AT-IE200-6GT

AT-x220-28GS

ATEN-VM6404H

BN-GS-2484P4X

HSA-500W

NG-GSM4328PB

PL-FSD-604HP

PL-FT-802

PL-GS-4210-24UP4C

PL-ICG-2510W-LTE

PL-VF-101G-KIT

RG-ES209GC-P

RG-LIC-WS-128

RG-M7800C-48GT4XS-P-EA

RG-M7805C-CM

RG-S5310-24GT4XS-P-E

  • System Accessibility and Availability
    • Secure in-band and out-of-band remote serial console access
    • Browser access with an intuitive GUI
    • Terminal-based access with a menu-driven UI
    • Modem dial-in/dial-back/dial-out access
    • Front USB ports for storage or USB-based PC cards
    • Laptop USB Console (LUC) port for local console access via laptop
    • Dual Ethernet ports allow fail control or dual IP address access
    • Dual power supply




  • Serial Console Management
    • Auto-sensing DTE/DCE feature supports a direct connection to Cisco network switches (and other compatible devices) without rollover cables for more convenient IT infrastructure deployment
    • Online/Offline detection of connected serial devices (including terminal blocks) – automatically send event notifications when the devices are offline for device status monitoring
    • Convenient and simple serial device access via selectable Telnet/SSH and third-party clients such as PuTTY
    • Easy port access via selectable ActiveX or Java serial viewer
    • Comprehensive viewer functions – copy/paste, logging, data import, macros, broadcasting and message board
    • Sun Solaris ready – Sun “break-safe”
    • Alert Strings – whenever one of the pre-defined strings matches the message sent from the serial devices, you will be informed by serial console server via SNMP Trap alert and/or an email
    • Command filter – administrators can restrict users to execute only pre-defined commands
    • Multiple users can simultaneously access the same port – up to 16 connections per port
    • Modes for simultaneous access – Exclusive/Occupy/Share
    • Integrates with ATEN PDU* products for power management of each port




  • Security
    • Supports secure login from browsers with TLS 1.2 data encryption and RSA 2048-bit certificates
    • Configurable user permissions for port access and control
    • Local and remote authentication and login
    • Third-party authentication via RADIUS, TACACS+, LDAP/AD and Kerberos
    • IP and MAC address filter for enhanced security protection
    • High-Grade Security – supports FIPS 140-2 level 1 security standards that use an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #1747, #2398, #2473)
    • Supports security level configuration – High, Medium-high, Medium or Custom, to ensure a fine granularity of network access control




  • System Management
    • System configuration via web browser, Telnet/SSH client and local console
    • System log and event login
    • Event Destination – Event logs will be saved to Log server, Syslog server, and USB drive
    • SNMP agent
    • Event notification – supports notification of SMTP email, SNMP Trap, and SMS (with additional mobile devices)
    • Backup / Restore system configuration and upgradeable firmware
    • Multi-browser support – Internet Explorer, Chrome, Firefox
    • NTP for time server synchronization
    • IPv4 / IPv6 support
    • Integrates into CC2000 software for centralized data center management
    • Integrates into CCVSR software for user session recording




  • Serial Device Management
    • Versatile serial operating modes – Console Management, Console Management Direct, Real COM Port, TCP Server/Client, UDP Server/Client, and Virtual Modem
    • Real COM driver for Windows 2000 or higher and Windows Server 2003/2008
    • Real TTY driver for Linux
    • Fixed TTY driver for UNIX**
    • Supports baud rates of 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200, 230400 bps




LanguageMulti-language web-based GUI – available in English, German, Japanese, Korean, Russian, Simplified Chinese and Traditional Chinese



Connectors
Serial 48 x RJ-45 Female
LAN Ports 2 x RJ-45 Female
Power 2 x IEC 60320/C14
Local Console 1 x RJ-45 Female
Modem 1 x RJ-45 Female
PON 1 x RJ-45 Female (Reserved)
Laptop USB Console (LUC) Port 1 x Mini USB
USB Port 3 x USB Type A Female
Switches
Power 2 x Rocker Switch
Reset 1 x Recessed Pushbutton
Maximum Input Power Rating 100–240VAC; 50/60Hz; 1.8A
Power Consumption AC110V:25.8W:153BTU
AC220V:26.2W:155BTU
LEDs
Serial 48 (Green)
10/100/1000 Mbps 2 (Red/Orange/Green)
Power 2 (Blue)
Mode of Operation Console Management, Console Management Direct, Real Com Port, TCP Server/Client, UDP Server/Client, Virtual Modem
Environmental
Operating Temperature 0 - 40˚C
Storage Temperature -20 ~ 60˚C
Humidity 0 - 80% RH, Non-condensing
Physical Properties
Housing Metal
Weight 4.92 kg ( 10.84 lb )
Dimensions (L x W x H) 43.84 x 32.77 x 4.40 cm
(17.26 x 12.9 x 1.73 in.)
